Gentex GWSSR Outdoor Red Lens Speaker Strobe

The Gentex GWSSR Outdoor Red Lens Speaker Strobe provides audible and visual notification for compatible emergency communication and mass notification systems. It combines a high-fidelity speaker with a selectable-candela LED strobe. In addition, its outdoor-rated enclosure supports installations that require additional protection from environmental conditions.

Outdoor Emergency Notification

The Gentex GWSSR belongs to the Commander 5 outdoor speaker/strobe family. It features a red strobe lens for applications that require a distinctive visual warning.

The speaker delivers voice messages and emergency notification tones. Meanwhile, the strobe provides a flashing visual signal during system activation.

As a result, the appliance combines audible communication and visual signaling in one assembly.

Selectable Red Lens Strobe Output

The red lens strobe provides six selectable light output settings:

• 10 candela
• 15 candela
• 30 candela
• 45 candela
• 60 candela
• 75 candela

Installers can select the appropriate setting according to the approved notification system design.

Therefore, one appliance can support several visual signaling requirements. The selected candela setting also affects electrical current consumption.

High-Fidelity Speaker Performance

The integrated speaker supports 25 VRMS and 70.7 VRMS emergency audio systems.

In addition, it provides six selectable power taps ranging from 1/8 watt to 4 watts.

The speaker supports a frequency range of 315 to 5000 Hz. Consequently, it can reproduce emergency voice messages and notification tones through compatible equipment.

Weather-Resistant Construction

The outdoor configuration includes a weatherproof cover and a compatible outdoor back box.

These accessories help protect the appliance from environmental exposure. Moreover, the clear protective cover allows the red strobe signal to remain visible.

Installers must follow the manufacturer’s mounting and sealing instructions to maintain the specified environmental protection.

Key Features

• Commander 5 outdoor speaker/strobe
• Red strobe lens
• High-fidelity speaker
• LED visual signaling technology
• Six selectable red-lens candela settings
• 10, 15, 30, 45, 60, and 75 cd
• Nominal 24 VDC strobe operation
• 16–33 VDC strobe operating range
• 25/70.7 VRMS speaker compatibility
• Six selectable speaker power taps
• 1/8W, 1/4W, 1/2W, 1W, 2W, and 4W
• 315–5000 Hz speaker frequency range
• Approximately 1 Hz strobe flash rate
• Universal wall or ceiling mounting
• Outdoor back box included
• Weatherproof protective cover
• Super-Slide mounting bracket
• Checkmate voltage verification
• Compatible Gentex synchronization
• Suitable for emergency communication systems
• Three-year manufacturer warranty

Speaker Power Tap Selection

The Gentex GWSSR provides adjustable speaker power settings for different notification requirements.

Installers can select lower wattage settings when the system design requires reduced audio output. Alternatively, higher wattage settings can provide increased sound levels.

However, each selected tap contributes to the total amplifier load. Therefore, technicians must calculate the speaker circuit requirements before installation.

Strobe Synchronization

The appliance supports compatible Gentex synchronization equipment, including the GTSM control module.

Synchronization allows multiple compatible strobes to flash together. As a result, the system can provide coordinated visual notification throughout the protected area.

The exact synchronization arrangement depends on the connected notification equipment.

Universal Mounting Design

This outdoor speaker/strobe supports both wall and ceiling mounting.

Its Super-Slide mounting bracket allows technicians to complete preliminary wiring before attaching the appliance.

In addition, Checkmate voltage verification helps installers evaluate circuit voltage during installation.

These features support convenient installation, testing, and maintenance.

Typical Applications

This red lens speaker/strobe can support commercial and industrial emergency notification applications.

For example, suitable locations may include manufacturing facilities, warehouses, transportation areas, parking structures, loading docks, and outdoor building locations.

The red visual signal can communicate a designated warning condition. However, the meaning of the signal depends on the approved emergency notification plan.

Installation and Compatibility

Before installation, verify the strobe voltage, candela setting, speaker voltage, wattage tap, and circuit capacity.

Also, confirm the required synchronization method and outdoor mounting accessories.

Qualified fire alarm and emergency communication professionals should install and test the appliance. Furthermore, technicians should follow Gentex instructions and applicable codes.

Overall, this Gentex outdoor speaker/strobe provides flexible audible and visual notification for compatible emergency communication systems. Its red lens, selectable candela settings, high-fidelity speaker, and weather-resistant mounting accessories make it suitable for demanding applications.
