Edwards G1RF-V1575 Genesis Red 15/75CD Wall Strobe

The Edwards G1RF-V1575 Genesis Wall Strobe provides visual fire alarm notification in a compact, low-profile appliance. This model features a red housing, clear lens, FIRE marking, and fixed 15/75 candela rating for compatible fire alarm notification systems.

Part of the Edwards Genesis Series, the G1RF-V1575 uses xenon strobe technology and is designed for wall-mounted fire alarm applications. Its compact construction provides a clean appearance while maintaining the visual signaling performance required for life-safety notification.

15/75 Candela Visual Notification

The G1RF-V1575 is a strobe-only notification appliance with a fixed 15/75 cd rating. The 15 cd rating applies under UL 1971, while the 75 cd rating applies under UL 1638.

The appliance operates from a regulated 24 VDC/FWR notification appliance circuit, with Edwards documentation specifying an operating range of 16 to 33 volts.

Key Features

• Genesis wall-mount visual notification appliance
• Fixed 15/75 candela strobe output
• Red housing with FIRE lettering
• Clear xenon strobe lens
• 24 VDC/FWR operation
• Compatible with Edwards synchronization systems

Compact Genesis Design

The Edwards G1RF-V1575 uses the compact Genesis housing designed to minimize appliance projection from the wall. The appliance mounts to standard electrical boxes without requiring a separate extension ring or trim plate in typical installations.

Edwards specifies an operating temperature range of 32°F to 120°F (0°C to 49°C). Compatible synchronization sources can synchronize multiple Genesis strobes within the same field of view.
